1. Unplug the power cord from the machine and wait 5 minutes. Place the
power cord in a secure location.
2. Using a #2 Phillips screwdriver, remove the indicated screw (with arrow)
from each of the Rear Roller Covers.
Note: Though the following image shows the Walking Deck raised, it is not
necessary to complete the next steps.
3. Using a #2 Phillips screwdriver, remove the indicated screw (with arrow)
from each of the Rear Roller Covers.
4. Remove the old Rear Roller Covers, and attach the new Rear Roller
Covers.
Note: To assist with reassembly, be sure to notice how the Endcap Base
Shroud is secured by the Rear Roller Cover.
!
To reduce the risk of electrical shock or unsupervised usage of the equipment, always unplug the power
cord from the wall outlet and wait 5 minutes before cleaning, maintaining or repairing this machine. Place
the power cord in a secure location.
Rear Roller Cover
Endcap Base
Shroud
Endcap Base
Shroud
Rear Roller Covers
To Next Page
