118
6. Using a #2 Phillips screwdriver, remove the indicated screw (with arrow)
from each of the Rear Roller Covers.
7. Remove the Rear Roller Covers and Endcap Base Shrouds.
Note: To assist with reassembly, be sure to notice how the Endcap Base
Shroud is secured by the Rear Roller Cover.
8. Using a #2 Phillips screwdriver, remove the 12 indicated screws from
below the Walking Deck that attach the Side Rails.
9. Remove the old Side Rails from the Walking Deck, and replace with the
new Side Rails.
10. Re-install all remaining parts that were removed in reverse order.
Rear Roller
Cover
Endcap Base
Shroud
To Next Page
