132
23. Using a 6mm hex wrench, remove the 2 indicated screws from the
Deck.
24. Lift and pivot the Front Roller out of the Frame, and slide it out of the
Walking Belt. This will free the Drive Belt from the Front Roller.
25. Using a 6mm hex wrench, nish removing the Adjustment Bolt from
the Rear Roller.
Note: Be sure to record the number of turns of the Adjustment Bolt it
takes to remove it. This will assist with reassembly.
Rear Roller
