19. Using a #2 Phillips screwdriver, remove the screws from the
Right Shroud ( 3 screws on the Right Shroud). Remove the upper
screws labeled ‘ * ’ last.
20. Using a #2 Phillips screwdriver, remove the 3 screws (indicated by arrows)
from the Brake Disc.
21. Carefully remove the Brake Disc from the machine exposing the lower Fan
Belt.
Right Side Left Side
*
*
Brake
Magnets
Brake
Disc
Fan Belt
