Bowflex TreadClimber TC1000 - Hardware and Tool List

13
Bowex
®
TreadClimber
®
Owner’s Manual
TreadClimber
®
Hardware and Tool List
Tools:
Qty: 6
Descr: 1/4” x 1” Flat Head Screw
Qty: 2
Descr: 5/16” x 1 1/2” Button Head Screw
Qty: 16
Descr: #10 Phillips Head Screw
Qty: 14
Descr: 5/16” x 1” Button Head Screw
Qty: 2
Descr: 5/16” Flat Washer
Qty: 12
Descr: 5/16” Flat Washer SAE
Qty: 4
Descr: 3/8” Cosmetic Plugs
Qty: 1
Descr: 5/16” Nylock Nut
Qty: 2
Descr: 5/16” Acorn Nut
Qty: 1
Descr: 3/8” x 3 3/4” Shoulder Bolt
Qty: 1
Descr: #2 Phillips Screwdriver Qty: 1
Descr: 3/16” Hex Key
Qty: 1
Descr: 9/16” Open End Wrench Qty: 1
Descr: 5/32” Hex Key
Parts:
Qty: 1
Descr: Drive Belt
Qty: 1
Descr: Safety Key with Clip (Models TC3000 & TC5000 only.)
NOTE: IMAGES BELOW ARE NOT TO SCALE
Hardware:
