9
Step12. The wiring scheme of sensor please refer to Fig.21, allow
some adjustments due to different cars.
Fig. 21
2. Installation of left/right signal lights harness
Step13. Take out the reversing lamp, turn on the right signal light, the
right-turn signal light is on, find out the 12v power cable with
multi-meter, connect the R_LAMP in harness cable with the 12v
power cable, and connect the L-LAMP in harness cable with the left
side power cable. (Fig.22-Fig.24)
Fig. 22 Fig. 23 Fig. 24
