PowerPro HP300 Series User Manual
1.3 Technical Specifications
GENERAL SPECIFICATIONS 10 15 20 30
Output kVA 10 15 20 30
Output kW 8 12 16 24
Output Power factor 0,8
Parallel Operation Up to 2 UPS (1 Redundant)
Hot Stand-by Operation Up to 2 UPS (1 Redundant)
Battery charging temperature compensation Optional
Emergency shutdown available
INPUT
Number of phase 3 phase
Input voltage 220/380 Vac or 230/ 400 Vac 3 phase ,N
Voltage tolerance +15% , -15%
By-pass voltage 220/380 Vac or 230/ 400 Vac 3 phase, N
Input frequency
50 Hz. ± 5%
RFI Level EN 50091
Split bypass connection available
OUTPUT
Number of phase 3 phase
Nominal Output voltage 220/380 Vac or 230/ 400 Vac 3 phase ,N
Voltage regulation tolerance
±1%
Nominal Output frequency 50 Hz
Output frequency tolerance (line syncron)
±2%
Output frequency tolerance (free running)
±0,2%
Efficiency 100% Load 90%
Load Crest Factor 3:1
Total Harmonic Distortion (THD) <3%
Overload 125% load 10 min.150% load 1 min.
BATTERY
Number of 30
Run time Optional
Float charge voltage 405 Vdc
End of charge voltage 300 Vdc
Boost charge available
Battery Test 1 time in 1 week (manuel test available)
Charge time <5 hours at full load
Battery trip available
INTERFACE
Communication
RS232(standart) RS485 (optional)
Up to 5 remote monitoring panel
Remote control
Dry contact Line failure,battery low,bypass,
EPO ,battery trip in/out
SNMP capability Optional SNMP adapter
Modem connection available
OTHER
Maximum temperature
0-40°C
Audible noise <60 dBA
Humidity %10-%90
Dimensions (HxWxD) (mm) 1145x485x675
