BPC PowerPro HP310 - 5.4 Connecting The UPS Power Cables

29
PowerPro HP300 Series User Manual
H-
P-
x
L-
Figure 5-1 Installation Diagram
5.4 Connecting The UPS Power Cables
CAUTION! Only qualified personnel should install or service UPS / batteries.
The ac input to the UPS should be supplied by a separate line from the ac distribution board.
The input/output cables can be sized to suit the modules rating according to the table below.
The connections of the electric panel should be supplied by grounded outlet. Cables enter the UPS modules
via entry panels in the base of cabinet. All control cables should be screened and run in a separate trunking
to the power cables.
The input/output cables can be sized to suit the modules’ rating according to the table below.
NOMINAL CURRENT : Amps / Recommended Cable Size (mm
2
)
BUS BAR CONNECTION
STUD SIZE
Input Mains
With full battery Recharge
Bypass / output
At full load
380V 400V 415V 380V 400V 415V
Battery
at min.
Battery
Voltage
UPS
RATING
(kVA)
A / mm
2
A / mm
2
A / mm
2
A / mm
2
A / mm
2
A / mm
2
A / mm
2
Input/Output
Cable
Terminations
U-V-W-N
Battery
Terminations
+ & -
10 22A / 6 20A / 6 19A / 6 16A / 6
15A / 6 14A / 6 28A / 6
16mm
2
Terminals
16mm
2
Terminals
15 32A / 6 30A / 6 28A / 6 23A / 6
22A / 6 21A / 6 41A / 10
16mm
2
Terminals
16mm
2
Terminals
20 43A / 10 39A / 10 37A / 10 31A / 10 29A / 10 28A / 10 55A / 16
16mm
2
Terminals
16mm
2
Terminals
30 64A / 16 59A / 16 56A / 16 46A / 10 44A / 10 42A / 10 82A / 25
35mm
2
Terminals
35mm
2
Terminals
NOTES: The neutral conductor should be sized for 1,5 times the output/bypass phase current. The Earth
conductor should be sized at 2 times the output/bypass conductor (this is dependent on the fault
rating, cable lengths, type of protection etc.) These recommendations are for guideline purposes
only and are superceded by local regulations and codes of practice.
10 15 20 30 UPS
(KVA)
3 Phase Input / Output
L - mm 485
P - mm 675
H - mm 1145
X (min.) - mm 250
