7
PowerPro HP300 Series User Manual
Parallel System
Data Socket
(DB25 Female)
RS232
Communication
Port
(DB9 Female)
Dry Relay Output Contacts
Parallel System
Current Samples
Socket
(DB15 Female)
Figure 1-3-a 10-15-20 kVA Power Switch Location
Battery Circuit
Breaker Input
Emergency
Stop
Line Failure
Relay
Battery Low
Relay
By-Pass
Relay
BATT
BATT
