Bpt MTMA/01 - General precautions; OPERATIONS FOR REMOTE CONTROL OF CALL BUTTONS; Manual configuration of terminals and as call inputs 1 and 2; BUTTON NUMBERING

1
3
5
7
2 1
4 2 1
6 3 2
1
1 2 1
8 4 3 2
Page 2 - Manual FB00329-EN - vers. 1
- 05/2016- © Came S.p.A. - The contents of the manual are to be considered as subject to change at any time and without the need for any advance warning.
General precautions
• Read the instructions carefully before beginning the installation and carry out the actions as specified by the manufacturer.
• The installation, programming, commissioning and maintenance of the product must only be carried out by qualified technicians,
properly trained in compliance with the regulations in force, including health and safety measures and the disposal of packaging.
• Before carrying out any cleaning or maintenance operation, disconnect the device from the power supply.
• The equipment must be destined solely for the use for which it was expressly designed.
• The manufacturer declines all liability for any damage as a result of improper, incorrect or unreasonable use.
OPERATIONS FOR REMOTE CONTROL OF CALL BUTTONS
Manual configuration of terminals and as call inputs 1 and 2
Short circuit the terminals ( and ), press and hold the two call buttons on the unit, and power the device. The unit restarts. The
procedure has been completed successfully.
Remove the short circuit and connect the additional N.O. buttons to the terminals
and .
BUTTON NUMBERING
