PREOPERATION
617 TRENCHER
GENERAL INFORMATION
The 617 trencher was designed to be easy to use and maintain. The
trencher mounts to the toolbar/attachment plate of the skid steer. The
mount incorporates the quick attach mechanism of the skid steer for fast,
easy mounting.
The trencher is powered by the skid steer's auxiliary hydraulic sys-
tem. Your skid steer
MUST have an auxiliary hydraulic system to run the
trencher. If your unit does not have an auxiliary hydraulic system, contact
your skid steer dealer reguarding the possible addition of such a system.
An adapter is needed to attach the trencher to the skid steer. Most
trenchers are shipped with the adapter already mounted to the trencher. If
yours was not shipped this way, see Section E for mounting kit installation.
To install the trencher on the skid steer see Section F. Operating instruc-
tions are covered in Section G.
Use the chart below to determine which trencher assembly is needed
for your specific skid steer. A diagram and parts list of all mounting and
hydraulic kits can be found in Section E and the trencher assembly can be
found in Section I.
FIT-UP CHART
COMPLETE MOUNTING &
SKID STEER TRENCHER ASSEMBLY HYDRAULIC
(Including Mtg. & Hyd. Kit) KIT ONLY
ASV Posi-Track 4500/4520 79090 79093
Bobcat 700/800/2000 79090 79093
Case 1835C/1840/1845C 79090 79093
Case 75XT/85XT/90XT/95XT 79090 79093
Case 1845B 79092 79105
Daewoo 601/801 79090 79093
Ford NH 775/778/779/784/785 79094 79106
Ford NH 553/555 79095 79108
Ford NH 465/485/565/665/865/885/985 79090 79093
Gehl 4510/4610/4515/4615 79310 79314
Gehl 4625/5625 79309 79311
Gehl 5635/6635 79090 79093
Hydra Mac 1700/2250/2650 (Universal Hitch) 79090 79093
JCB 165 79090 79093
JCB 185/1105 85494 85493
John Deere 675 79095 79108
John Deere 875 79094 79106
John Deere 4475/6675/7775/8875 79090 79093
5760
11-16-98-3
DD
