DECALS
Q
Q
DECAL PLACEMENT
617 TRENCHER
GENERAL INFORMATION
The diagram on this page shows the location of all the decals used on the
617 trencher. The decals are identified by their part numbers, with reductions of
the actual decals located on the following pages. Use this information to order
replacements for lost or damaged decals. Be sure to read all decals before
operating the trencher. They contain information you need to know for both
safety and trencher longevity.
4350
40113
40114
40161
4167
40113
40113
4338
40116
40114
40117
4105
4498
4084
5822
9-15-92-2
40115
4495
4498
40161
