Bradco 617 - Trencher Component Nomenclature

PREOPERATION
TRENCHER MAJOR COMPONENT NOMENCLATURE
617 TRENCHER
GENERAL INFORMATION
The purpose of this page is to acquaint you with the trencher and the
names of its various components. This knowledge will be helpful when
reading through this manual or when ordering service parts.
SIDE SHIFT
MOUNTING
FRAME
SIDE SHIFT
LOCKING PIN
HYDRAULIC MOTOR
CRUMBER END
CRUMBER
SHOE
CRUMBER BOOM
CHAIN GUARD
DIGGING BOOM
DIGGING CHAIN
TOOTH
HEADSHAFT
AUGER
CHAIN TENSION
ADJUSTMENT
CRUMBER BOOM
ADJUSTMENT
BUILT-IN SKID
SHOE
