NO REQ'D PART NO. DESCRIPTION
1 2 35792 Hose Assembly, .62" x 82"
(SAE 100R2-2Wire) 8MP-10MB-HS
2 2 59065 Pin
3 1 68935 Trencher Attaching Bracket
4 8 1089 .50" UNC x 1.25" Hex Capscrew
5 8 1516 .50" Flat Washer
6 8 1505 .50" Lock Washer
7 8 1228 .50" UNC Hex Nut
8 8 1649 .75" Hard Flat Washer
9 8 1137 .75" UNC x 1.50" Hex Capscrew
MOUNTING KIT INSTALLATION
TRENCHER MOUNTING KIT #79105
5766
2-13-92
E
E
