NO REQ'D PART NO. DESCRIPTION
1 2 1054 .38" UNC x 3.75" Hex Capscrew
2 8 1514 .38" Flat Washer
3 4 53038 Crumber Roller
4 4 53039 Crumber Roller Bushing
5 2 1536 .38" UNC Nylock Nut
6 1 53087 Crumber End
7 2 1226 .38" UNC Hex Nut
8 2 1503 .38" Lock Washer
9 2 1044 .38" UNC x 1.25" Hex Capscrew
10 2 54067* Idler Spacer
11 1 79103* Idler Wheel
12 1 8085* Idler Bearing
13 1 53988* Idler Bearing Hub
14 2 40161 Decal - Stand Clear
15 1 53068 48" Crumber Bar / Personal Restraint Bar
16 2 53138 Boom Bushing
17 1 79088 48" Boom
18 1 53188 Spring
19 1 53132 1.12" Square Pin
20 1 62717 Boom End
21 1 1548 .75" UNC x 1.25" Nylock Capscrew
22 2 62702 Adjusting Bolt
23 2 1245 .75" UNC Jam Nut
24 2 1231 .75" UNC Nut
TRENCHER ASSEMBLY
48" BOOM AND CRUMBER
ASSEMBLY #79084
5756
4-17-96-4
NOTE: Idler Roller Assembly Repair Kit #80868 includes all parts marked
with an asterisk (*).
II
