NO PART NO. DESCRIPTION
1 83802 Carbide Bit Holder - 4" Right
2 83801 Carbide Bit Holder - 4" Left
3 54432 Cup Cutter - Right
4 54431 Cup Cutter - Left
5 83804 Carbide Bit Holder - 5" Right
(1) Weld Spot on Top for Identifying Purposes
6 83803 Carbide Bit Holder - 5" Left
(1) Weld Spot on Top for Identifying Purposes
7 83806 Carbide Bit Holder - 6" Right
(2) Weld Spots on Top for Identifying Purposes
8 83805 Carbide Bit Holder - 6" Left
(2) Weld Spots on Top for Identifying Purposes
9 83800 Spacer - 6" Cut
10 1692 .50" UNF Hex Nut
11 51547 Carbide Bit
12 83798 Tube Spacer
(Inside Mount Carbide Bit Holder)
13 54628 Tube Spacer
(Inside Mount Cup Cutter)
14 54440 Tube Spacer
(Outside Cup or Carbide Bit Holder)
15 1347 .50" UNF X 3.25" Hex Capscrew
16 1349 .50" UNF X 3.75" Hex Capscrew
17 1351 .50" UNF X 4.50" Hex Capscrew
18 1348 .50" UNF X 3.50" Hex Capscrew
19 1350 .50" UNF X 4.00" Hex Capscrew
COMBINATION ROCK AND FROST CHAIN
2.00" PITCH - TOOTH EVERY STATION
SERVICE PARTS
6825
1-26-96
NOTE: There are weld spots located on the top of the 5" and 6" Carbide
Bit Holders to assist in parts identification. One weld spot on the 5" Hold-
ers and two weld spots on the 6" Holders.
