DIGGING CHAIN OPTIONSDIGGING CHAIN OPTIONS
DIGGING CHAIN OPTIONSDIGGING CHAIN OPTIONS
DIGGING CHAIN OPTIONS
2.00" PITCH DIGGING CHAIN WIDTH CONVERSIONS
J
J
6) FROM 10" WIDE TO 8" WIDE
REQ’D PART NO. DESCRIPTION
2 1351 .50"UNF X 4.50" Capscrew
2 54628 Spacer Tube
8 54440 Spacer Tube
1 54439 8" Spacer
1 53055 8" Crumber Shoe
CHAIN CONVERSIONS FOR 48" BOOMS - TOOTH EVERY STATION
1) FROM 6" WIDE TO 8" WIDE
REQ’D PART NO. DESCRIPTION
28 1351 .50"UNF X 4.50" Capscrew
2 54440 Spacer Tube
14 54439 8" Spacer
1 53055 8" Crumber Shoe
2) FROM 8" WIDE TO 6" WIDE
REQ’D PART NO. DESCRIPTION
28 1347 .50"UNF X 3.25" Capscrew
2 54628 Spacer Tube
1 53054 6" Crumber Shoe
CHAIN CONVERSIONS FOR 30" BOOMS - TOOTH EVERY OTHER STATION
1) FROM 6" WIDE TO 8" WIDE
REQ’D PART NO. DESCRIPTION
8 1351 .50"UNF X 4.50" Capscrew
4 54439 8" Spacer
1 53055 8" Crumber Shoe
2) FROM 8" WIDE TO 6" WIDE
REQ’D PART NO. DESCRIPTION
8 1347 .50"UNF X 3.25" Capscrew
1 53054 6" Crumber Shoe
3) FROM 6" WIDE TO 10" WIDE
REQ’D PART NO. DESCRIPTION
4 1692 .50" UNF High Hex Nut
8 1351 .50"UNF X 4.50" Capscrew
1 54431 Left Tooth
1 54432 Right Tooth
2 54441 10" Chain Spacer
1 53058 10" Crumber Shoe
4 54439 8" Spacer
6678
10-4-95
