PLANER ASSEMBLY
9854 7-27-07-3
ITEM REQ’D PART NO. DESCRIPTION
20 5 1044 .38" UNC X 1.25" Hex Capscrew
5 1503 .38" Lock Washer
5 1514 .38" Flat Washer
5 1226 .38" UNC Hex Nut
21 2 1102 .50" UNC X 5.00" Hex Capscrew
22 1 18656 Door (16" & 18" Planer)
1 17663 Door (24" Planer)
1 19545 Door (30" Planer)
1 101130 Door (40" Planer)
23 1 19560 Latch
2 1043 .38" UNC X 1.00" Hex Capscrew
2 1503 .38" Lock Washer
2 1514 .38" Flat Washer
2 1226 .38" UNC Hex Nut
24 2 17666 Spacer Tube
25 2 1841 .50" UNC Deformed Lock Nut
26 8 10003 .62" UNF Deformed Oval Lock Nut
27 1 18534 Drum Assembly with Teeth (16" Planer)
1 18535 Drum Assembly with Teeth (18" Planer)
1 18524 Drum Assembly with Teeth (24" Planer)
1 19712 Drum Assembly with Teeth (30" Planer)
1 101080 Drum Assembly with Teeth (40" Planer)
28 1 18970 Planetary
-- 30355 Replacement Oil Fill Plug
29 -- 17776 Hydraulic Motor (Not available on 40" Planer)
2.0 Cu. In. / Blue / 22 GPM - 28 GPM
-- 17777 Hydraulic Motor Option (Not available on 40" Planer)
2.5 Cu. In. / Black / 29 GPM - 35 GPM
-- 17778 Hydraulic Motor Option (Standard on 40" Planer)
3.0 Cu. In. / Red / 36 GPM - 44 GPM
** 45845 Replacement Seal Kit
30 2 1090 .50" UNC X 1.50" Hex Capscrew
2 1646 .50" Hard Flat Washer
2 1505 .50" Lock Washer
31 2 101467 Spacer Tube
32 1 102594 Motor Gasket
33 6 1780 .50” UNC X 1.25” Hex Capscrew
34 1 101140 Idler Plate
35 4 1832 .62” UNC X 1.50” Hex Capscrew - Grade 8
4 1506 .62” Lock Washer
36 1 100947 Bearing
37 8 10070 .62” UNC X 1.75” Hex Capscrew - Grade 8
8 1506 .62” Lock Washer
38 1 103025 Bearing Mounting Plate
16”, 18”, 24”, 30” & 40” COLD PLANER ASSEMBLIES
LIST 2 OF 3
NOTE: There may be a slight quantity difference in hardware between the various cold
planers. Quantity listed is for the 24" planer.
** Field replacement of internal motor seals voids warranty.
