INSTALLATION
9833 7-27-07-3
GENERAL INFORMATION
The following instructions will help you to mount your planer onto your skid steer loader.
The planer uses the quick-attach system for ease of installation. Therefore, if you know how to
attach your loader bucket, attaching the cold planer should prove no problem.
Remember to read all safety warnings, decals and operating instructions before operat-
ing the attachment. If there is any portion of this manual that you do not understand, contact
your dealer.
WARNING! THE 16", 18", 24", 30" AND 40" PLANERS ARE DESIGNED FOR USE ON
HIGH FLOW HYDRAULIC SYSTEMS.
DO NOT ATTACH OR OPERATE ANY ATTACHMENT THAT EXCEEDS THE
RECOMMENDED LIFTING CAPACITY OF YOUR SKID STEER.
INSTALLATION INSTRUCTIONS
1. Remove the shipping banding from around the planer and skid.
2. Remove any attachments from the front of the loader.
3. Following all standard safety practices and the instructions for installing an attachment
in your skid steer operator's manual, install the planer onto your skid steer.
NOTE: It is important to make sure the locking mechanism on your quick attach is engaged,
therefore locking the attachment onto the skid steer.
4. Lower the unit to the ground and remove the key.
5. Relieve any pressure from the auxiliary hydraulic system. After making sure that there is
not any foreign matter on the hydraulic couplers connect the case drain coupler to the
case drain on your skid steer loader. NOTE: The case drain line must be connected rst,
then the power and return hoses. When disconnecting the hoses, it is recommended to
disconnect the case drain line last.
6. Connect the power and return couplers to the high ow auxiliary hydraulic system of your
skid steer loader. Route the hose in such a fashion as to avoid pinching or chang.
CAUTION! BE SURE CASE DRAIN COUPLER IS COMPLETELY ENGAGED. IMMEDIATE
HYDRAULIC MOTOR SEAL FAILURE AND PLANETARY DAMAGE WILL OC-
CUR IF CASE DRAIN IS NOT SUCCESSFULLY CONNECTED.
7. Connect the electrical wire harness from the cold planer to the auxiliary electrical connec-
tor on the front of the skid steer (if so equipped). If your skid steer is not equipped with an
electrical connector and you are using the BRADCO control handle, connect the wiring
harness to the control handle and place the control handle inside of the skid steer opera-
tor's station.
WARNING! Do not operate the cold planer from outside of the skid steer operator's sta-
tion.
