ITEM REQ’D PART NO. DESCRIPTION
1 2 19196 Clamp Plate (16" & 18" Planer)
2 17757 Clamp Plate (24" Planer)
2 19548 Clamp Plate (30" Planer)
2 101118 Clamp Plate (40" Planer)
2 4 19198 Wear Strip (16" & 18" Planer)
4 89611 Wear Strip (24" Planer)
4 19550 Wear Strip (30" Planer)
8 19198 Wear Strip (40" Planer)
3 2 19199 Shim (16" & 18" Planer)
2 89612 Shim (24" Planer)
2 19551 Shim (30" Planer)
2 101121 Shim (40" Planer)
4 2 19197 Spacer Plate (16" & 18" Planer)
2 17758 Spacer Plate (24" Planer)
2 19549 Spacer Plate (30" Planer)
2 101119 Spacer Plate (40" Planer)
5 1 89501 Side Shift Frame
6 1 18648 Pivot Plate (16" & 18" Planer)
1 17661 Pivot Plate (24" Planer)
1 19543 Pivot Plate (30" Planer)
1 101116 Pivot Plate (40" Planer)
7 2 17732 Spacer Tube
8 1 17730 Plate
9 5 1142 .75" UNC X 2.75" Hex Capscrew
5 1507 .75" Lock Washer
5 1649 .75" Hard Flat Washer
10 1 88996 Cap Plate
11 2 1139 .75" UNC X 2.00" Hex Capscrew
2 1507 .75" Lock Washer
2 1649 .75" Hard Flat Washer
12 1 88995 Guide Plate
13 1 89436 Bushing
14 1 17733 Spacer
15 1 18893 Shim
16 12 1818 .50" UNC X 2.75" Hex Capscrew Grade 8
12 1505 .50" Lock Washer
17 1 100213 Extracting Tool (Pick Puller)
NOTE: There may be a slight quantity difference in hardware between the various cold
planers. Quantity listed is for the 24" planer.
PLANER ASSEMBLY
16”, 18”, 24”, 30” & 40” COLD PLANER ASSEMBLIES
LIST 3 OF 3
