Bradley S19-2200 - Page 4

EFX 60/S19-2200 Installation
4 2/26/2018 Bradley • 215-1289 Rev. P; ECN 18-09-005
(mm)
22-3/4" (577)
Door
10-1/8"
(258)
7-5/8"
(194)
8-3/4"
(222)
26"
(663)
24"
(608)
Wall Flange
2" (53)
1-1/4" NPT
Outlet
9/32" Dia. Holes
(4) each side,
(8) Total
6-1/2"
(165)
2"
(51)
1" NPT
Inlets
2-3/4"
(70)
5"
(128)
1-3/4"
(46)
18"
(457)
28"
(711)
26-1/2"
(676)
Door
2-1/4" (57)
30"
(765)
Bottom View
Side View
Front View
Mounting Hole Locations
9-3/4"
(248)
9-3/16"
(233)
24"
(610)
20"
(508)
5-1/4"
(130)
2"
(51)
2"
(51)
1/2" Dia. Holes
(6) Places
Optional Recessed Cabinet
Optional Surface-Mounted Cabinet
Wall Opening:
24-1/2" W x 28-1/2" H
22-3/4" (577)
Door
10-1/8"
(258)
7-5/8"
(194)
8-3/4"
(222)
24"
(608)
1-1/4" NPT
Outlet
6-1/2"
(165)
1" NPT
Inlets
2-3/4"
(70)
1-3/4"
(46)
28"
(711)
26-1/2"
(676)
Door
2-1/4" (57)
Bottom View
Side View
Front View
