INSTALLATION
2
2.1
Replacing Existing Thermostat cont.
4.
After labeling and removing all wires from terminals, unscrew the existing thermostat
sub-base from wall. Make sure to secure wires to prevent them from slipping back
into the hole in the wall.
NOTE: This thermostat is designed for use with a 24 Volt AC low voltage
multi-stage heat pump system. Do not use this thermostat on applications with
voltages above 30 Volts AC.
2.2
Installing Your New Thermostat
NOTE: If you are installing this thermostat in a new installation be sure to locate
the thermostat 4 to 5 feet above the floor in accordance with applicable building
codes. Make sure to install the thermostat in a location that provides good airflow
characteristics and avoid areas behind doors, near corners, air vents, direct sunlight
or near any heat generating device. Installation in any of these areas could impact
thermostat performance.
TESTING YOUR
NEW THERMOSTAT
3
NOTE: Test your thermostat prior to programming any user settings. Pressing the
RESET button will erase any user entries for time of day, day of week, option settings
and programming if previously programmed. This will erase all user settings and
return them to their default values.
WARNING!
Read BEFORE Testing
• Do not short (or jumper) across terminals on the heating or cooling system
control board to test the thermostat installation. This could damage the thermostat
and void the warranty.
• Do not select COOL mode of operation if the outside temperature is below
50˚ F (10˚ C). This could possibly damage the controlled cooling system and may
cause personal injury.
• This thermostat includes an automatic compressor protection feature to avoid
potential damage to the heat pump system from short cycling. This thermostat
automatically provides a 5-minute delay after turning off the heating or cooling
heat pump output to protect the compressor.
cont.
PROGRAMMING
4
4.1
Default Thermostat Settings
Function Status After Reset
Operation Mode Normal Operating Mode
Temperature Hold Permanent and Temporary Hold Cleared
Clock 12:00 pm, Monday
Room Temperature 70˚ F (21.0˚ C), to be renewed within
5 seconds
Setpoint Temperature According to system switch:
62˚ F (17.0˚ C) for Heat and Off
83˚ F (28.0˚ C) for Cool
Temperature Scale ˚F or ˚C dependent on switch setting
Operating Program DAY program, Monday
Low Battery Warning Off, to be renewed within 5 seconds
First Stage Differential 0.5˚ F (0.25˚ C)
Second Stage Differential 2˚ F (1.0˚ C)
Short Cycle Protection Timer Reset
Output Relays Off
Filter Check Monitor 0 days-off
Extended Hold Indefinite
Adaptive Recovery Mode Reset
1. Place the system switch in the HEAT position.
2. Press the button on the keypad until the setpoint temperature setting is a minimum of 3
degrees higher than the current room temperature. The heating system should start within
several seconds. The fan may not turn on immediately due to the heating system built-in
fan delay.
3. Place the system switch in the OFF position. The heating system should stop within
several seconds.
4. Wait 5 minutes for the automatic compressor short cycle protection period to expire, or press the
RESET button to bypass this feature for initial testing purposes. Pressing the RESET button will
erase any user entries previously programmed.
5. Place the system switch in the COOL position.
6. Press the button on the keypad until the setpoint temperature is a minimum of 3 degrees
lower than the current room temperature.
7. The cooling system should start within several seconds. Place the system switch in the OFF
position. The cooling system should stop within a few seconds.
8. Place the fan switch in the ON position. The system blower should start.
9. Place the fan switch in the AUTO position. The system blower should stop.
1.
Always turn off power to the air conditioning or heating system prior to installing your
new thermostat.
2.
Place system switch on front of thermostat to the OFF position.
3.
Place fan control switch on front of thermostat to the AUTO position.
4.
Remove front of thermostat body from sub-base by pressing release latch on bottom of
front body.
5.
Place the thermostat sub-base against wall in the desired thermostat location.
6.
Guide thermostat wires through center hole in sub-base. Continue to hold sub-base
against wall.
7.
Mark placement of mounting holes as appropriate and drill using a 3/16" drill bit.
8.
Gently tap supplied plastic anchors into the holes in the wall.
9.
Place the thermostat sub-base against the wall in the desired location, making sure the
mounting holes are aligned as appropriate and the thermostat wires are properly inserting
through opening in middle of sub-base.
10.
Fasten the sub-base to wall using supplied screws.
11.
Connect wires to quick wiring terminal block as appropriate using the new terminal
designations. Refer to Wiring Diagram section of this manual if required for assistance.
12.
Make sure all of the wire connections are secure and are not touching any other
terminal to prevent electrical shorts and potential damage to the thermostat.
13.
Turn the front thermostat body over, exposing the rear view of the circuit board.
14.
Locate the internal ˚F / ˚C switch on the circuit board.
15.
Using your fingers, gently flip the switch toward the preferred temperature ˚F / ˚C scale.
16.
Attach front body of thermostat to sub-base of thermostat, being careful to align the
terminal pins on the front body with the terminal block on the sub-base
.
17.
Open front thermostat door and open battery compartment door.
18.
Install two new "AA" alkaline batteries into battery compartment. Make sure to locate
the positive (+) ends of the batteries and match them with the positive (+) terminals
located in the battery compartment.
19.
Close battery compartment.
20.
Restore system power so you can test installation.
