8. Protocol Examples: ASCII
Command Response Description Supported Devices
%aannttccff !aa Set device conguration All Devices
#** No
Response
Synchronised sampling ED-549
#aa >(Data) Read analogue input of all channels ED-549
#aan >(Data) Read the analogue input of one channel ED-549
#aan(Data) > Set the output value for one channel ED-560
$aa0Ci !aa Perform span calibration on a channel ED-549
$aa1Ci !aa Perform zero calibration on a channel ED-549
$aa2 !aannttccff Read the device conguration All Devices
#AA0BDD > Set Digital Output of Upper 8 Channels Digital Output Devices
#AA1cDD > Set a Single Digital Output of Lower 8
Channels
Digital Output Devices
#AAAcDD > Set a Single Digital Output of Lower 8
Channels
Digital Output Devices
#AAN !AA(Data) Read Digital Input Counter Digital Input Devices
$AA4 !S(Data) Read Synchronized Data All Devices
$AA5 !AAS Read Reset Status All Devices
$AA6 !(Data) Read Digital I/O Status All Devices
$AAC !AA Clear Latched Digital Input Digital Input Devices
$AACN !AA Clear Digital Input Counter Digital Input Devices
