Brainboxes ED 5 Series - Pin Outs & Leds

3
ED-516 : 16 digital inputs
Type of
Port
Terminal
Block
Pin 1 Pin 2 Pin 3 Pin 4 Pin 5
Digital In Yellow -V DIn 0 DIn 1 DIn 2 DIn 3
Digital In Orange -V DIn 4 DIn 5 DIn 6 DIn 7
Expansion Grey SIG GND RS-485 D- RS-485 D+ RS-485 D+ RS-485 D-
Digital In Green -V DIn 8 DIn 9 DIn 10 DIn 11
Digital In Blue -V DIn 12 DIn 13 DIn 14 DIn 15
Power Black -V +VA +VB -V Func. GND
2. Pin Outs & LEDs
Link LED Green light on Network Link Established
Flashing Green Network Data RX/TX
Status LED Green Device Ready
Flashing Yellow Changing Settings
Flashing between Red & Green Querying IP
Flashing Green and Red User performing Hard Reset
Flashing between Green & Red/Yellow IP address diagnostic
Flashing between Green & Yellow Initialization diagnostic
Activity LED Flashing Green Output set/Input Read
Flashing Red Output overload
Expansion
LED
Flashing Green RS-485 data TX/RX
Flashing Red RS-485 Comms error
