Brainboxes ED 5 Series - Overview

2
1. Overview
Outputs, Inputs or Relay
RS-485 NuDAM/
ADAM Module
Expansion Port
Ethernet port
Outputs or Inputs
LED Status
Indication
Integral snap-on DIN
rail mount
+5VDC to +30VDC Power supply Inputs
Ventilation
Functional
Earth contact
to DIN rail
