Brainchild P41 User Manual

Addr.
Func.
CRC16
06 00 0x5B 00 02
Hi
Lo
Query
DataHi/LoData Hi / LoRegister Addr.Register Addr.
Addr. Func.
CRC16
03 00 0x5C 00 09
Hi
Lo
Query
No. of wordsNo. of words
Example3:Perform reset function
Addr. Func.
CRC16
06 00 0x8E
0x68
0x25
Hi
Lo
Query
DataHi/LoData Hi / Lo
Register Addr.Register Addr.
Starting Addr.Starting Addr.
Example 4 : Enter auto-tuning mode
Addr. Func.
CRC16
06 00 0x0B
00 03
Hi
Lo
Query
DataHi/LoData Hi / Lo
Register Addr.Register Addr.
Example 5 : Enter manual mode
Addr. Func.
CRC16
06 00 0x0B
00 05
Hi
Lo
Query
DataHi/LoData Hi / Lo
Register Addr.Register Addr.
Example 6 : Modify the Calibration coefficient
Preset the CMND register with 26668 before attempting to change the
calibration coefficient.
Addr. Func.
CRC16
06 00 0x8E
0x68 0x2C
Hi
Lo
Query
DataHi/LoData Hi / Lo
Register Addr.Register Addr.
UM0P411A
90
