Branson 2000X aed - For a 15 Khz System; For a 20 Khz System

4-34 100-214-276 Rev. 3
Chapter 4: Installation and Setup
Assemble the Acoustic Stack
4.8.1 For a 15 kHz System
4.8.2 For a 20kHz System
Step Action
1
Clean the mating surfaces of the converter, booster, and horn. Remove any
foreign material from the threaded holes.
2
Install the threaded stud into the top of the booster. Torque to 450 in-lbs,
50.84Nm. If the stud is dry, apply 1 or 2 drops of a light lubricating oil before
installing.
3
Install the threaded stud into the top of the horn. Torque to 450 in-lbs, 50.84Nm.
If the stud is dry, apply 1 or 2 drops of a light lubricating oil before installing.
4
Install a single Mylar washer (matching the size of the washer to the stud) to
each interface.
5 Assemble the converter to the booster and the booster to the horn.
6 Torque to 250 in-lbs, 28.25 Nm.
Step Action
1
Clean the mating surfaces of the converter, booster, and horn. Remove any
foreign material from the threaded holes.
2
Install the threaded stud into the top of the booster. Torque to 450 in-lbs, 50.84
Nm. If the stud is dry, apply 1 or 2 drops of a light lubricating oil before installing.
3
Install the threaded stud into the top of the horn.Torque to 450 in-lbs, 50.84 Nm.
If the stud is dry, apply 1 or 2 drops of a light lubricating oil before installing.
4
Install a single Mylar washer (matching the size of the washer to the stud) to
each interface.
5 Assemble the converter to the booster and the booster to the horn.
6
Torque to 220 in-lbs, 24.85 Nm. (Torque 20kHz Solid Mount Converter to 250 in-
lbs, 28.25Nm.)
