5-2 100-214-276 Rev. 3
Chapter 5: Technical Specifications
Technical Specifications
5.1.2 Performance Specifications
The following tables detail some of the performance specifications associated with the 2000X
Actuator.
Table 5.2 Maximum Welding Force (at 100 psig and 4.0” stroke)
Table 5.3 Dynamic Trigger Force
Table 5.4 Dynamic Follow-Through
Table 5.5 Maximum Traverse Speed (Application dependant)
Minimum Stroke: 1/8” / 3.2 mm
Maximum Stroke: 3-3/4” / 95.2 mm (for a 4" cylinder)
1.5" cylinder 135 lb. / 61.4 k
2.0” cylinder 269 lb. / 122.3 k.
2.5" cylinder 441 lb / 200.5 k.
3.0” cylinder 651 lb. / 295.9 k. (Horn dependant for 15 kHz)
3.25" cylinder 772 lb. / 350.9 k.
1.5" and 2.0" cylinder 5 lb. / 2.25 k to max force
2.5", 3.0", and 3.25" cylinder 10 lb./ 4.5 k. to max force
3.0" cylinder (15 kHz) Horn dependant
1.5", 2.0" 15 lb. / 6.8 k. to max force
2.5", 3.0", 3.25" 15 - 400 lb. / 6.8 - 181.8 k.
Down and Return
Speed
Up to 7 inch/ 177.8 mm per sec. max at 3.5-inch / 88.9 mm
stroke, 90 psi (all cylinder sizes)
DOC EXPIRES 12PM 7/24/2012. Article or Material must comply with the requirements
stipulated by RoHS in its current version
