CHAPTER 4 TRANSMISSION 3015R(h)/3515R(h)/4015R(h)/F36R(h)/F42R(h) TRACTOR
2.6 REAR AXLE






13121511
1
2
3
4
9
7
8
10
6
5
14
F42W429A
 (1)Countershaft
 (2)Ringgear
 (3)Differentialcase
 (4)Pinionshaft
 (5)Differentialpinion
 (6)Differentialsidegear(B)
 (7)Differentialsidegear(A)
 (8)Differentialthrustassembly
 (9)Finalpinion(R)
 (10)Finalpinion(L)
 (11)Rearaxlegear(LH)
 (12)Rearaxlegear(RH)
 (13)Rearaxle
 (14)Oilseal
 (15)Rearaxlehousing
Whenrotatingforcearrivesatthecountershaft(1),itrotatesthedifferentialcase(3)throughtheringgear(2).
Asthedifferentialrotates,thedifferentialpinion(5)anddifferentialsidegear(7)insidethedifferentialcaseto
delivertherotatingforcetothenalpinion(9).
Then,thespeedoftherotatingforceatthenalpinionisreducedthroughengagementofthe16gearofthe
nalpinionwiththe65rearaxlegear(11),anditisnallytransmittedtotherearaxle(13),whichisconnected
withsplines,inordertorotatetherearwheels.
2.7.1 POWER TRANSFER
