Branson DC 222 - Page 37

Description of the Unit
4-9
Digital Compact
2002 BRANSON Ultrasonics Digital Compact Version 22.08.2002
Fig. 4-5 Controls on the front panel of the
DC 222 power supply module
Ultrasonics on
Reset
Test
Maximum power window (green)
Power bar graph (red)
Amplitude
setting
Tuning
Potentiometer
Max/min power
Connector for
power
measuring signal
J4 RS232 interface
(not required in normal operation)
Mains supply
Overload
Weld time or
energy setting
Time welding
Energy welding
