OPERATION DESCRIPTION
4
COOLANT TEMPERATURE GAUGE
This coolant temperature gauge indi-
cates the engine coolant temperature
after the ignition switch is turned to
the "ON" position. If the needle reads
the red area, immediately stop work-
ing and then inspect the tractor.
(1) Coolant Temperature Gauge
A42O409A
TACHOMETER/HOUR METER
The tachometer indicates the engine
rpm and the hour meter indicates the
total run hour of the tractor.
(1) Tachometer (2) Hour Meter
A42O408A
