Page 8
Lift Installation Instructions
Installation Parts
Please check the Installation Parts List and Tools List to see that you have everything needed to begin.
Report any missing items.
Tools Required
• Pencil
• Tape measure
• Framing square
• Hammer
• Center punch
Power Cable and Base Plate Wedges: These items fastened to the lift platform during shipment.
• Wire stripper/Utility knife
• 3/8" Capacity drill
• 1/8" Diameter drill bit
• 3/8" Diameter drill bit
• 9/32" Diameter drill bit
• 9/16" Wrenches and/or socket
• 1-1/8" Diameter hole saw
• 1/4" Hex nut driver bit or
• 1/4" socket/wrench
• Ratchet-style wrench
Item Qty. Description Part No.
1 Installation Parts Package (complete) Includes all following items 25853A-A4
1 4 Bracket, Underfloor, Reinforcement 25915-04
1 Small Parts Package (Bag) only (includes items 2-20 only) 25926A
2 2 Bolt, 3/8"-16 x 8" Hex Tap (Full Thread) 10778
3 8 Bolt, 3/8"-16 x 4" Carriage 23977
4 2 Bolt, 3/8"-16 x 1" Hex 10025
5 8 Washer, 2.469" O.D. x .5" I.D., Flat 13342
6 14 Washer, 3/8" Flat 10064
7 4 Washer, 3/8" Lock 10069
8 8 Washer, 3/8" External Tooth Star 25844
9 2 Washer, 5/16" External Tooth Star 16368
10 10 Nut, 3/8"-16 Hex 10059
11 18 Screw, #8-18 x 1/2" Hex, Self-Tap 10383
12 6 Screw, #8-18 x 1" Hex, Self-Tap 10084
13 2 Screw, 5/16-18 x 3/4", Thread Cutting 21735
14 10 Clip, Cable, 7/16" Diameter Plastic 15777
15 5 Cable Tie, 11" Solid 10091
16 1 Grommet, Plastic 205-2001
17 1 Terminal, Battery Cable, 1/4" eye 13865
18 1 Boot, Rubber, Battery Cable 82046
19 2 Spacer, 13/32" I.D. x 1/2" 13050
20 2 Plastic End Cap, 1" I.D. x 1-1/4" O.D. 20474
21 1 Circuit Sentry Kit 28910KS
22 1 Lead Wire - 30" 13362A
23 1 Cable, Chassis Ground 22166A
24 1 Control Box Holder Assembly Includes: 17019A
25 1 Plate, Back 16988
26 1 Bracket, Switchbox Clip 16954
27 2 Decal, Courtesy Requested 12375
28 1 Decal, Warnings/Operating Instructions 27204
29 1 Decal, Instructions, ADA (Standee/Interlock) 19342
30 1 Video, Commercial Lift Operation 28332
31 1 Manual, Installation/Service 30469
32 2 Grip, Handrail, Yellow 19074
