Page 52
11.00
HANDRAILS
11.10
Faulty
Operation
11.11 Slide support arm guide bolts
improperly adjusted (tightness),
missing or damaged
11.12 Worn bushings/pivot pins
11.13 Pivot pins misaligned (snap ring
missing) or otherwise damaged
11.14 Handrail bent, deformed or
otherwise damaged
12.11 See 2.30 and 9.42
12.12 Defective dampening springs
Correct or replace
Replace
Correct or replace
Correct or replace
Replace dampening springs
FUNCTION SYMPTOM POSSIBLE CAUSE REMEDY
12.00
Lift-Tite
™
Latches
12.10
Faulty
Operation
Troubleshooting Diagnosis Chart
10.10
Up/Fold
(Faulty Operation)
10.20
Down/Unfold
(Faulty Operation)
10.00
MANUAL
BACKUP
PUMP
10.11 See 8.11, 8.22, 8.24 and 8.41
10.12 Lost prime
10.13 Air leak at backup pump to pump
interface (O-rings)
10.21 See 3.20
10.22 Lift platform has drifted against
Lift-Tite
™
latches
Prime.
See Systems Descriptions for
Priming and Flushing procedure
Check tightness or leaks
Pump lift platform fully up then release
