Page 19
CONTACT REMOVAL
1. Remove orange wedge using
needle nose pliers or a hook shaped
wire to pull wedge straight out.
2. To remove the contacts, gently
pull wire backwards, while at the
same time releasing the locking
finger by moving it away from the
contact with a screwdriver.
3. Hold the rear seal in place, as
removing the contact will displace
the seal
Troubleshooting Diagnosis Chart
