Page 22
Unfold for:
Lift Wiring
Schematic
Hydraulic Parts List
Item Qty. Description Part No.
1 1 Pump Assembly (M259 with Reservoir/with Back-up pump) 87060-24V
2 1 Motor, Pump 16504-IS
3 1 Valve, “Down” (with Solenoid) 16505
4 1 Clamp, Reservoir - H-48 17069
5 1 Reservoir Replacement Kit (Includes Item #10) 88188K
6 2 O-Ring (only), Hand Pump Mounting 17351
7 1 Hand Pump (Backup) with O-Rings (Includes Item #6) 87065
8 1 Handle with Grip 17206W
9 3 Screw, 1/4-20 x 1 3/4”, Allen Head 17352
10 1 Fitting, 3/8” Male NPT x 3/8” Barbed 87618
11 2 Clamp, Hose - 5/8” O.D. - Worm Drive 84325
12 1 Tubing, 3/8” x 5/8”, Tygothane - Clear 82066R012
13 1 Plug, 3/8” Plastic Hose 81580
14 1 Fitting, 90°-1/8” Male Pipe x 1/8” Barbed 87563
15 1 Tube, 1/4” O.D. x 1/8” I.D. - Plastic 81557R014
16 1 Plug, 1/8” Plastic Tube 81583
17 2 Adapter, 1/4” Male NPT x 7/16-20 Male JIC 37° 10130
18 1 Fitting, Tee, 7/16-20 Male JIC 37° (3) 30793
19 1 Hose Assembly, 1/4” - Female Swivel 7/16-20 JIC 37° 32785A-202
20 1 Fitting, 90° - 9/16-18 Male O-Ring x 7/16-20 JIC 37° 87622
21 1 Coupling, Hydraulic Quick Connect x 1/4” Female NPT 87614
22 1 Nipple, Hydraulic Quick Connect x 1/4” Female NPT 87615
23 1 Elbow, 90° - 1/4” NPT Street 10114
24 1 Nut, 9/16-18, Hex Jam 83077
25 1 Fitting Assembly, Bulk Head 73777A
26 1 Hose Assembly, 3/16” - Female Swivel 7/16-20 JIC 37° 915-5603-080.5
27 1 Fitting, 9/16” Male O-Ring x 7/16-20 Male JIC 37° 26787
28 2 Valve, Flow Control 87053
29 2 Adaptor, 916-18 Male O-Ring to 1/4” Male NPT 31646
30 1 Fitting, Tee - 1/4” Male NPT (1) x 1/4” Female NPT (2) 11340
31 1 Adapter, 7/16-20 Female O-Ring to 1/4-18 Male NPT 29305
32 1 Switch, Pressure Transducer 30426
33 2 Fitting, 90° - 1/4” Female Swivel NPT x 7/16-20 Male JIC 37° 26789
34 2 Cylinder, UVL Retracting 87055N
35 2 Hose Assembly, 1/8” - Female Swivel 7/16-20 JIC 37° 16004A-020
To Next Page
