Page 34
Exploded Views and Parts Lists
Platform Assembly - Front Handrail Lock
Platform Assembly - Rear Handrail Lock
6
4
3
1
7
2
5
BAR-HANDRAIL LOCK REAR33478
WELDMENT-HANDRAIL LATCH REAR
DESCRIPTION
33668
33669
PART NO.
34178W
ITEM
4
3
2
1
6
5
6
1
3
QTY.
1
NUT-HANDRAIL LOCK
WASHER-.5ID X 1.003OD X .057-.067THK PTFE
1 82348 BOLT-5/16-24 X 1 SKT BTN PLTD
7
2 29942 BOLT-3/8-16 X 1/2" FLBHSCS 6G8/PATCH
843841 ROD END-5/16-24 MALE
6
4
5
1
7
3
2
BAR-HANDRAIL LOCK FRONT33426
WELDMENT-HANDRAIL LATCH FRONT
DESCRIPTION
33668
33669
PART NO.
34177W
ITEM
4
3
2
1
6
5
8
1
4
QTY.
1
NUT-HANDRAIL LOCK
WASHER-.5ID X 1.003OD X .057-.067THK PTFE
1 82348 BOLT-5/16-24 X 1 SKT BTN PLTD
7
2 29942 BOLT-3/8-16 X 1/2" FLBHSCS 6G8/PATCH
843841 ROD END-5/16-24 MALE
