16
Series 5A and Series 5B I.S. Valve Status Monitor
Installation, Operation and Maintenance Manual
No. Description Imperial Metric
1 Dome Bolts
5B0000-22900536 5B0000-22950536
2 Dome Washer
3 Dome Assembly
4 Dome Gasket
5 Indicator Assembly
6 Cover Bolt
5B0000-22901536 5B0000-22951536
7 Cover Bolt Washer
No. Description Imperial and Metric
1 Dome Bolts
5B0000-22952536*
2 Dome Washer
3 Dome Assembly
4 Dome Gasket
5 Indicator Assembly
6 Cover Bolt 5A0000-72102534
*Dome repair kit only for S5B Resin
16. Replacement Parts
16.2 Replacement Parts Resin Housing
16.1 Replacement Parts Aluminum Housing
17. Basic Tools
Common To All Units
Terminal Connections Screwdriver, ¼” tip flat blade
All switches, terminal strip Screwdriver, No. 1 Phillips
Ground screw Screwdriver, No. 2 Phillips
Imperial Style
Indicator Dome Wrench, 5/16”
Cover Bolt, Aluminum Housing Hex Key, 5/32”
Cover Bolt, Resin Housing Hex Key, 4mm
Conduit Entry – ½” NPT Hex Key, 3/8”
Conduit Entry – ¾” NPT Hex Key, 9/16”
Mounting Bracket Bolts Wrench, 5/16" & 7/16"
Metric Style
Indicator Dome Wrench, 8mm
Cover Bolt Hex Key, 4mm
Conduit Entry – M20 Screwdriver, No. 3 Phillips
Conduit Entry – M25 Screwdriver, No. 3 Phillips
Mounting Bracket Bolts Wrench, 8mm & 10mm
