BREN Razor 700 Series User Manual

BREN 700-Series User Manual
Installation
2-3
Please pay attention to the direction of the base beam (the wheel on the front end of the
beam comes with a break while the rear one is on its own).
Step 3
Place the stand beam upright on the T-stand and follow number  to assemble (See
Figure 2.2-4 & 2.2-5). There is hexagon socket head screws fasten on the T-stand on both
side taken as locating pins.
Step 4
Position the stand beam perpendicularly to part and put the screws into the holes and
tighten them as Figure 2.2-5. Then the complete picture of stand will be like Figure 2.2-4.
Front Rear
Figure2.2- 2
 T-Stand

Stand beam
Figure 2.2-4
Figure 2.2-5
Figure2.2- 3

BREN Razor 700 Series Specifications

General

Brand	BREN
Model	Razor 700 Series
Category	Cutter
Language	English
