BREN 700-Series User Manual
Installation
2-4
Step 5
Remove the cutting plotter from the carton. Position your stand under the plotter, on the
bottom of the plotter, there is one hole on each side in the position corresponding to the
locating pins, so the locating pins can be located into the holes. Then insert the screws into
the holes on the stand to fix the plotter and tighten them up as shown in Figure 2.2-6.
Screws
Figure 2.2-6
