21
4.3.6 MULTI-CHANNEL AND SCROLL MODE FOR OPTIONAL SENSORS
You can add up to 7 additional Thermo-
Hygrometer sensor (optional, refer to section
3.2). Press the [ CH ] key to switch between
indoor and Channels 1 to 7.
For auto-scroll function, just press and hold the [ CH ] key for 3 seconds and the icon will
appear next to CH. The console will scroll the readings of all the sensors every 3 seconds.
This mode shown below information:
- Channel number of the current sensor
- Temperature and humidity reading of this sensor
- Signal strength of this sensor.
- Sensor type icon (for water pool or soil moisture sensor)
4.3.7 WATER LEAK (OPTIONAL LEAK SENSOR)
You can add up to 7 additional Water Leak sensors (optional,
refer to section 3.2)
The channel number(s) of the corresponding water leak sensor(s)
added to the console will be shown with the NO LEAKING icon.
When water leaking is detected, the channel number of the sensor
detecting the leaking will ash together the LEAKING icon.
NOTE:
When low battery is detected, the channel number of the sensor detecting the low battery
condition will ash once every 4 seconds.
4.3.8 WIND
4.3.8.1 WIND SPEED AND DIRECTION SECTION OVERVIEW
Wind direction
Real time wind
direction indicator
Past wind directions
indicator of last 5
minutes (maximum 6)
Average / Gust
Wind speed or
Beaufort scale
Wind speed
level indicator
A solid arrow indicates the current real-time wind direction, whereas the bars indicate up to six
dierent wind direction of the past 5 minutes.
4.3.8.2 WIND SPEED, GUST AND BEAUFORT SCALE DISPLAY
Press [WIND] key to switch display between Average wind speed, Gust, and Beaufort scale.
The wind level provides a quick reference on the wind condition and is indicated by a series of
text icons
Level LIGHT MODERATE STRONG STORM
Speed
2-8 mph
3-13 km/h
9-25 mph
14-41 km/h
26-54 mph
42-87 km/h
≥ 55 mph
≥ 88 km/h
