6
1.1 QUICK START GUIDE
The following Quick Start Guide provides the necessary steps to install and operate the
weather station, and upload to the Internet, along with references to the pertinent sections.
Step Description Section
1 Power up the 7-in-1 sensor array 3.1.3
2 Power up the display console and pair with sensor array 3.4
3 Manually set date and time (This part is unnecessary if the weather
station is connected to PWL later)
4.4.1
4 Reset the rain to zero 4.3.10.2
5 Create account and register weather station at PWL 5
6 Connect weather station to WI-FI 6.1, 6.2, 6.3
2. PRE INSTALLATION
2.1 CHECKOUT
Before permanently install your weather station, we recommend the user to operate the
weather station at a location which is easy to access to. This will allow you to get familiar with
the weather station functions and calibration procedures, to ensure proper operation before
installing it permanently.
2.2 SITE SELECTION
Before installing the sensor array, please consider the followings;
1. Rain gauge must be clean every few months
2. Avoid radiant heat reected from any adjacent buildings and structures. Ideally, the sensor
array should be installed at 1.5m (5’) from any building, structure, ground or roof top.
3. Choose an area of open space in direct sunlight without any obstruction of rain, wind, and
sunlight.
4. Transmission range between sensor array and display console could reach a distance of
150m (or 450 feet) at line of sight, providing there are no interfering obstacles in between
or nearby such as trees, towers, or high voltage line. Check the reception signal quality to
ensure good reception.
5. Household appliance such as fridge, lighting, dimmers may pose Electro-magnetic
interference (EMI), while Radio Frequency Interference (RFI) from devices operating in the
same frequency range may cause signal intermittent. Choose a location at least 1-2 meter
(3-5 feet) away from these interference sources to ensure best reception.
