ALTAIR 8800 micro Users Manual
© Briel Computers 2010 page 38
Appendix C: Bill of materials
DESCRIPTION QTY
ATMEL ATMEGA8515 AVR CPU 1
62256 SRAM CYPRESS 70NS 1
74HCT573 LATCHES 8
PROPELLER CHIP 1
EEPROM 1
5MHz CRYSTAL 1
20MHz CRYSTAL 1
LM7805 VOLTAGE REGULATOR 1
LM3940 VOLTAGE REGULATOR 1
40 PIN SOCKET 2
28 PIN SOCKET 1
20 PIN SOCKET 8
8 PIN SOCKET 1
2 position on/off toggle 21
3 WAY MOM TOGGLE 3
100 OHM RESISTORS 2
220 OHM RESISTORS 38
470 OHM RESISTORS 3
560 OHM RESISTOR 1
1K OHM RESISTOR 1
3.3K OHM RESISTORS 5
4.7K OR 3.9K OHM SIP RESISTORS 3
.1uF CAPACITORS 12
22pF CAPACITORS 2
10uF CAPACITORS 2
100uF CAP 1
1N4001 DIODE 1
PS/2 KEYBOARD CONNECTOR 1
RCA YELLOW VIDEO CONNECTOR 1
VGA CONNECTOR 1
HEADER CONNECTORS 5
SD CARD CONNECTOR 1
RED LED'S 32
2.1MM DC POWER CONNECTOR 1
CASE 1
FRONT CUSTOM PANEL 1
REAR BRUSHED PANEL 1
MAINBOARD PCB 1
FRONT PANEL PCB 1
CD 1
RIBBON CABLE 2
4-40 MOUNTING SCREWS 10
4-40 NUTS 2
