Frequency Modulated Continuous Wave (FMCW)
Manufacturer Deutsch
Part Number DT06-4S-CE06 (female)
0.7kg (including pigtail cable)
Sensor: IP69K (Protected from dust & strong water jets)
Connector: IP68 (Protected from dust &immersion into water)
Four 5.2mm diameter holes on 198mm horizontal centres,
and 40mm vertical centres.
Unit is supplied with M5x30mm screws and M5 polymer
locknuts for mounting purposes. Recommended torque is
5.6Nm, (50 inch/lbs approx.).
Optional, adjustable for vertical angle. See section 2.2
typ. 0.27 at 12Vdc / typ. 0.14A at 24Vdc
Max. 2.0A at 9Vdc when connected to 2x BS-9000, 2x BE-
800C with heaters & IR active
5A, automotive (regular size) blade fuse type, located on red
power supply cable
System supply positive, negative, activation inputs and trigger
outputs
7 pigtail cables exiting from front face of ECU
Rating 0Vdc to 32Vdc
System active above 9Vdc, inactive below 7Vdc
Active State: switched to ground up to 0.5A
Inactive State: High impedance (> 1 MOhm)
ISO 7637 (over and reverse voltage protection)
Approvals
CE
ECE Regulation No. 10
ISO 16750
ISO 13766
EN 13309
FCC
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may
not cause harmful interference, and (2) this device must accept any interference received, including interference that may
cause undesired operation.
Any change or modifications not expressly approved by the responsible party responsible for compliance could void the user’s
authority to operate the equipment.
Brigade Electronics
BS-XXXX
