7 Specifications
Operation Characteristics
Detection range
5 zones in configurable lengths
Model name
BS-9001-OSD
[m]
[ft]
Detection Area length
2.5 - 30
8 – 98
Each Detection Zone length
0.5 – 28
2 - 92
Detection Area Width
2 - 10
7 - 33
Nominal tolerance
±0.25m / 1ft
Radar beam angle
Horizontal 120° out to the maximum designated width
Vertical 12°
(symmetrically perpendicular to sensor front surface)
Distance resolution
≥ 0.5m (~2ft) (limitations apply, see section 1.2 for details).
Object detection
≤ 0.5second (limitations apply, see section 1.2 for details).”)
Power on to system ready
≤ 9 seconds
System standby to active
≤ 0.5 second
Communication between BS-9000 sensor and BS-OSD-022
Physical layer
CAN bus 2.0A Base Frame Format
Protocol layer
Proprietary Protocol. See BS-9000 Installation and Operating
Guide for details
Max. cable length between
termination points
30m (98ft approx.)
ECU Specification
On-Screen Indicators
High visibility coloured indicators. Configurable screen
location based on sensor CAN ID. Transparency level is
configurable.
Audible Alert
Volume control via display monitor controls.
Pulse rate (without volume control) mirrored onto External
Alarm Trigger for synchronous warning on peripheral alarm.
Programming interface
USB A plug, (pigtail cable)
Dimensions (all in mm)
193 x 95 x 35 (Excluding pigtail cables)
Connectors
Various – See product drawings
Cable lengths
300mm nominal
Weight
0.5kg (including pigtail cables)
Operating temperature
-40°C to +85°C
IP Protection
IP30 (not water protected)
Mounting
Integral mounting flanges accept M5 screw (not supplied)
