The illustration on the following page shows a completed
transfer switch installation. Your actual layout will vary.
Illustration callouts are:
A - From utility watt-hour meter
B - Current transformers
C - Transfer switch enclosure
D - T/R and GND to Generator
E - Transfer switch control board (TRCM)
F - Neutral terminal
G - Neutral bus
H - Ground bus
J - Main distribution panel
K - UTILITY 240VAC to Generator
L - Two pin connector or Two pin terminal block
M - Ten pin connector or Eight pin terminal block
N - Generator circuit breaker
P - Generator
R - Generator Neutral terminal
S - Generator Ground terminal
T - Transfer switch ground terminal
U - Load connection to distribution panel
V - Utility disconnect circuit breaker
W - Utility connection
X - Generator connection
