Page | 14
Level 0 Level 1 (On screen) Level 2 (On screen) Parameters (On screen)
(INTEGRAL GAIN)
* Derivative Gain (Kd)
(DERIVATIVE GAIN)
0 – 1000
* Friction Setoff
(FRICTION SETOFF)
0 – 1000
* Gain Schedule Trigger
(GAIN SCHEDULE TRIGGER)
0.0 – 100.0 %
* Loading Factor
(LOADING FACTOR)
0 – 1000
* Unloading Factor
(UNLOADING FACTOR)
0 – 1000
Start/Stop
Configuration
(STR/STP DEV
CNFG)
* Running Steps
(RUNNING STEPS)
0 – 500
(MISC SETTINGS)
PASSWORD 1
* ####
0 – 9 for each digit
PASSWORD 2 #### 0 – 9 for each digit
PASSWORD 3 #### 0 – 9 for each digit
(RESET
COUNTERS)
(GENSET)
* (RUN TIME)
(In hours)
(NO. OF STARTS) (In numbers)
(NO. OF TRIPS) (In numbers)
(SELECT PROFILE)
(SELECT PROFILE) (Profile Name) A – Z, 0 – 9
(DATE AND TIME)
(DATE) (DD / MM / YYYY) 0 – 9 for each digit
(TIME) (Hours) (In hours)
(ACTUATOR TEST)
(ACTUATOR TEST)
(ENABLE) Yes/No
(TEST DURATION) 0 – 10 sec
* Note: Certain parameters can only be changed by the dealer while others can only be changed by the
manufacturer (designated by an *). Some default parameters are subject to change during firmware updates
per the manufacturer. The dealer password is available on the Briggs and Stratton
®
Power Portal.
Operating Modes
4
There are two modes of operation:
Auto Mode
Manual Mode
Auto Mode
4.1
To enter Auto Mode, push the “AUTO” key. While in Auto Mode, the generator will start and run under
any one of these conditions:
Auto Mains Failure (AMF)
Remote Start/Stop (2 Wire)
Auto Exercise
Auto Mains Failure (AMF)
4.1.1
When the Mains Monitoring is enabled (default setting) in the Mains configuration and the controller is
in the Auto Mode, AMF mode gets activated.
In this mode, if the Mains is healthy, the genset remains in the OFF condition. When the Mains voltage
drops below a certain threshold, the controller gives a start command. Once the genset is started and
its loading parameters reach the threshold values, the genset contactor is latched and the load is
To Next Page
