Briggs & Stratton Power Products Home Generator System
Owners Manual
UNIT PARTS LIST
Item Part # Qty. Description
1 H190724GS 1 CRADLE
2 H92531GS 1 SUPPORT, Engine
3 H190723GS 1 SUPPORT, Engine & Muffler
4 92247GS 1 HOUSING, Engine Adapter
5 191308GS 1 ASSY, Rotor (Inclds Item 7)
6 94981AGS 1 ASSY, Stator
7 65791GS 1 BEARING
8 96796GS 1 WASHER, Grommet Retainer
9 22129GS 5 LOCKWASHER
10 86307GS 4 CAPSCREW, Hex Head
11 75431GS 1 CAPSCREW, Hex Head
12 92609GS 2 MOUNT,Vibration
13 82857GS 4 MOUNT,Vibration
14 67989GS 2 NUT, Flange Serrated
15 66476GS 2 CAPSCREW
16 92532GS 1 BRACKET, Muffler
17 22142GS 2 SCREW
18 B4206GS 1 MUFFLER
19 B4343GS 1 GASKET, Muffler
20 81917GS 1 PIN, Roll
21 83083GS 1 SCREEN, Spark Arrest
22 22127GS 2 NUT, Hex
23 22097GS 2 WASHER, Lock
24 22287GS 2 SCREW
25 SRV66825DGS 1 CARRIER, Rear Bearing
26 74908GS 4 TAPTITE
27 86308BGS 4 BOLT, Stator
28 65795GS 1 RECTIFIER, Battery Charge
29 66849AGS 1 TAPTITE
30 67022GS 1 GROMMET, Rubber
31 84132GS 1 ASSY, Power Regulator
32 66386GS 1 ASSY, Brush Holder
33 66849GS 2 TAPTITE
34 B4871GS 1 COVER, Bearing Carrier
35 22769GS 1 WASHER, Shakeproof Int.
36 86494GS 1 SCREW,Wing
37 188333GS 1 DECAL, Instruction, Fuel Level
38 77395GS 4 NUT, Flange Lock
39 83465GS 4 GROMMET,Tank
40 78831AGS 4 CAPSCREW, Hex Head
41 80270GS 1 VALVE,Tank
42 78299GS 1 BUSHING, Plastic Tank
43 B4363GS 1 CAP, Fuel Gauge
Item Part # Qty. Description
44 B1998GS 1 ASSY,Tank, Fuel
(Includes Items 41 & 42)
45 J189176GS 1 SHIELD, Heat
46 92665GS 1 INSULATION
47 85000GS 1 CLIP, Insulation
48 14353621GS 1 WIRE, Ground
49 26850GS 2 LW, EXT, Shakeproof
51 92982GS 1 DECAL, Danger
52 B2153GS 7 DRILLER, Self
53 189160GS 12 NUT, Serrated Flange
54 190725GS 2 DECAL,Tank Support
57 190725GS 1 DECAL, Control Panel
58 B4690GS 1 ASSY, Control Panel
59 43116GS 4 CAPSCREW, Hex Head
60 22531GS 2 CAPSCREW, Hex Head
62 93826GS 1 DECAL, Start Instructions
63 JB4674GS 1 SHIELD, Heat
64 56893GS 5 CRIMPTITE
65 77282GS 1 SWITCH, Starter
66 B4986GS 1 DECAL, Ground
68 30340GS 1 HOSE, Fuel
69 48031CGS 2 CLAMP, Hose
70 189302CGS 2 ASSY,Wire, #13
71 13353621GS 1 ASSY,Wire, #55
72 J186704GS 1 TRAY, Battery
73 96113GS 1 ASSY,Wire, #13
74 52618GS 2 CAPSCREW, Hex Head
75 190911GS 1 MANUAL, Engine
76 52856GS 2 NUT, Hex, Flange
77 23897GS 2 WASHER, Flat
78 B4489GS 1 BATTERY
79 190732GS 1 MANUAL, Owners
80 62265GS 2 GROMMET
81 73054GS 1 DECAL, Fuel Shut-Off
82 77816GS 1 DECAL, Caution Hot Muffler
83 78549GS 1 DECAL, Electric Start
84 190780GS 1 DECAL, 1-800 BSPP
85 BB3061GS 2 BOTTLE, Oil
86 B4177GS 1 CHARGER, Battery
87 B5066GS 1 FLASHLIGHT
88 190854GS 1 MANUAL, Installation
89 24114GS 2 NUT
90 42907GS 1 CAPSCREW, Hex Head
900 NSP 1 ENGINE

Briggs & Stratton Home Generator System Specifications

Electrical Specifications

rated maximum load current at 25°C/77°F, LP	83.3 Amps
rated AC voltage	240 Volts
phase	Single phase
rated frequency	60 Hertz

Operating Environment

normal operating range	-20°F (-28.8°C) to 104°F (40°C)
output sound level at normal load	68 dB(A) at 23 ft. (7 m)

Weight and Dimensions

shipping weight	575 lb (260 kg)
