Brightlink 16x16 - Page 6

6
IN3
3D
7.1CH
IN4
4K2K
NONE
IN5
D1024
D1024=DVI 1024 x 768
IN6
D1080
D1080=DVI 1920 x 1080
IN7
D1200
D1200=DVI 1920 x 1200
IN8
OUT1
OUT1=Copy OUTPUT1 EDID to INPUTx
ALL
OUT2
ALL=Set EDID to ALL INPUTs
OUT2=Copy OUTPUT2 EDID to INPUTx
OUT3
OUT3=Copy OUTPUT3 EDID to INPUTx
OUT4
OUT4=Copy OUTPUT4 EDID to INPUTx
OUT5
OUT5=Copy OUTPUT5 EDID to INPUTx
OUT6
OUT6=Copy OUTPUT6 EDID to INPUTx
OUT7
OUT7=Copy OUTPUT7 EDID to INPUTx
OUT8
OUT8=Copy OUTPUT8 EDID to INPUTx
10. Up Selection Button – Press to change segment’s value
11. ESC – Press to quit EDID set mode
12. Lock LED Indicator -- Indicate the status of Lock.
13. Lock Button -- Press to lock the buttons of the front panel
14. HDMI Input/ Output composite button 6 to 8– Press to select Input 6 to 8 or Output 6 to 8.
Or combine with other button to select Input/ Output channel when Input/ Output is high
than 9.
15. HDMI Input/ Output multiple button 9 -- Press to select Input 9 or Output 9. Or combine
with other button to select Input/ Output channel when Input/ Output is high than 9. This
button also can be used to control cursor to Right under “MENU” editable status.
16. HDMI Input/ Output multiple button 0 -- Combine with other button to select Input/ Output
channel when Input/ Output is high than 9. This button also can be used to control cursor
to Down under “MENU” editable status.
17. PTP Button -- Press to mirror all inputs and outputs (e.g. output 1 to input1, output 2 to
input2 and so on).
18. Selection Button -- Press to select segment to change setting. Selected segment will be
blinking.
19. Down Selection Button -- Press to change segment’s value.
20. Enter Button -- Press to set EDID to specified INPUT or copy EDID from specified
OUTPUT to specified INPUT.
