23
Note: When performing Step 10,
Lift grill body from front and
rear panels to avoid injury to
hands and fingers. Be sure
to pass hose/regulator
assembly above cart frame
crossbar.
Step 10
With the help of a friend, place grill
body assembly on preassembled
cart frame. Grill body will rest on
angled top of vertical supports.
Align bolt holes located on the
outside of the grill body assembly.
Secure using four M6 X12mm bolts
with star washers.
Grill Body
Assembly
To Next Page
