27
Step 14
Attach side burner igniter lead
wire to electrode as illustrated.
Step 15
Place side burner grate on the
side burner.
Step 16
Insert grease cup into the grease
tray. Make sure to slide cup onto
tracks as illustrated.
Grease Cup
Side Burner
Grate
Electrode
Side Burner
Igniter Lead Wire
